See How We Fix ThisYIDI Motion Ball Splines: Built for Demanding Linear Motion
Our ball splines combine splined shaft precision with recirculating ball technology. Shafts ground from SCM415 or SCM440 alloy steel, hardened to 58-62 HRC. Nuts feature Gothic arch grooves for 4-point contact, handling radial, axial, and moment loads up to 10x rod-only systems.
Why choose us? We focus on what matters in real ops. Tolerances hit JIS C3 to C10 standards. Ball diameters from 3.175mm up. Multi-start grooves optional for higher speeds.
Picture a pick-and-place robot arm. Traditional splines chatter under torque. Ours run silent at 2m/s, with preload damping vibes. Or factory automation slides—our splines cut wear by extending service life to 50,000km under load.
- Zero backlash with fixed or adjustable preload.
- High rigidity: Torque ratings 200-5000Nm depending on size.
- Compact design: Nut OD as low as 20mm on 8mm shaft.
- Corrosion options: Phosphate or black oxide coatings.
- Lube ports standard for grease fitting.
Not just specs on paper. We've shipped these to US automation firms tackling semiconductor wafer handling. They report smoother motion profiles, less servo strain.
Custom? We do OEM/ODM from prototype to 10k/month. Ends machined to your blueprint, shafts fluted per DIN 5480 or custom profile.
Short story: A Canadian importer switched to us after a competitor's splines pitted after 6 months. Their new setup? Zero failures in 18 months, running 24/7.
Email for Custom SpecsInside Our Hebei Factory: 100+ Staff, German/Japanese Tech
YIDI Motion kicked off in 2020, but our core team brings 20+ years from top linear motion plants. 100 employees, 30% senior techs. We imported Okuma grinders from Japan and DMG CNCs from Germany. That means micron-level repeatability, not guesswork.
Production flow? Bar stock inspected, rough turned, induction hardened, flute ground, superfinished. Nuts milled, heat treated, ball-assembled under clean room. Full CMM metrology per ISO 9001.
Certifications? ISO 9001:2015, CE marked for EU. RoHS compliant materials. Traceability via lot codes back to raw stock.
Proud exports to 50+ countries: USA, Germany, Japan, Canada.
We handle one-stop: ball screw, linear guides, modules too. But ball splines? Our sweet spot for high-torque linear needs.
Tour Factory CapabilitiesBall Spline Technical Specs Table
Standard range covers most needs. Custom beyond this— no issue.
| Shaft Dia (mm) | Nut OD (mm) | Dynamic Load (kN) | Static Load (kN) | Accuracy Grade |
|---|---|---|---|---|
| 8 | 20 | 2.5 | 5.1 | C5-C10 |
| 16 | 32 | 9.8 | 19.6 | C3-C7 |
| 25 | 45 | 21.5 | 42.0 | C3-C5 |
| 36 | 60 | 38.2 | 74.5 | C3 |
| 50 | 80 | 62.7 | 122 | C3 |
Loads per 300mm stroke. Full catalog has 20+ sizes. Preload boosts stiffness 20-30%.
Tolerances: Shaft straightness 0.02/300mm, flute pitch error 3 microns max.
Where Ball Splines Excel in Real-World Applications
ball screw spline supplier wholesale ball screw spline custom ball screw spline
Multi-axis robots. Shaft telescopes inside nut for compact strokes. Handles side loads that pins snap under.
Heavy-duty actuators. Pair with ball screws for hybrid motion—spline takes torque, screw precision travel.
Factory automation: Transfer lines moving 200kg pallets. Our 36mm units shrug off misalignment.
- Semicon equip: Wafer stages, zero particle gen.
- Packaging machines: Vertical lifts with high cycle rates.
- Medical devices: Surgical robots needing sterile, backlash-free motion.
- Defense: Telescoping masts, UAV gimbals.
One US client built electric vehicles test rigs. Our splines endured 10^6 cycles at 5g accel. Solid.
How to Pick a Ball Spline Manufacturer: Procurement Checklist
Start with load calc. Dynamic Cn & static Co from catalogs. Factor 1.5-2x safety.
Ask for shaft material certs—SCM440 min, carburized case depth 1mm+.
Grinding proof: Post-grind roundness charts.
Lead time reality: 25-35 days stock mods, 45-60 custom.
MOQ? We start at 10pcs for samples. Scale to pallets.
Request Free Sample KitPractical Installation and Maintenance Notes
Mount nut flange-parallel to base, ±0.02mm. Use dial indicator on shaft.
Lube: Lithium grease NLGI 2, every 1000km or 500hrs.
Alignment key. Misalign by 0.1mm? Balls pit fast.
Maintenance: Wipe grooves yearly, check preload torque.
Pro tip: Add end wipers for dusty shops. Extends life 2x.
Shipping to USA: 25-40 Days Door-to-Door
FOB Tianjin port. LCL or FCL—2000pcs fit 20ft container.
DHL samples: 5-7 days, $200-400.
Customs HS code 8483.40. Duties ~3%. We provide commercial invoice, packing list.
Tracked via sea freight partners. Incoterms: EXW/CIF your call.
Recent US shipment: 500 splines to California, 28 days total.
Get Detailed Shipping QuoteWhat Buyers Say About Our Ball Splines
