6002RS Bearing: Precision Sealed Deep Groove Ball Bearings for Demanding Applications

Looking for a dependable 6002RS bearing that handles high speeds and everyday wear without failing prematurely? We've supplied thousands to U.S. importers, machine shops, and OEM lines over the past few years. These are 15x32x9mm deep groove ball bearings with double rubber seals—built for motors, pumps, and conveyor systems where contamination is a real headache.

At YIDI Motion, we don't just stock them. Our Hebei factory runs them on German-imported grinders and Japanese precision assembly lines. Lead times? Typically 7-15 days for bulk, FOB Tianjin. Skip the middlemen and get factory-direct pricing that beats Alibaba spot deals.

Request 6002RS Specs Sheet | Talk Factory Engineer

Procurement managers in the U.S. often hit snags sourcing small-bore bearings like the 6002RS. Spot market prices fluctuate, quality varies wildly from unknown exporters, and those double-sided rubber seals (2RS) can leak grease if the contact isn't spot-on. We've seen it firsthand—jobs halt when a $2 bearing fails in a spindle or fan motor.

That's where our 6002RS steps in. Standard dimensions: 15mm inner diameter, 32mm outer, 9mm wide. Rated for 4300 RPM dynamic load, 2100 static, with a typical lifespan pushing 20,000 hours under moderate duty. Not hype—these numbers come from real dyno tests we run before shipment.

Back in 2020, when YIDI Motion fired up, we targeted linear motion parts but quickly expanded into bearings because buyers kept asking. Our 100-person team, 30% senior techs, handles everything from SF1 bushing parallels to these sealed balls. Exports to 50+ countries, including steady U.S. routes via LAX and ORD.

One importer from Ohio told us last quarter: "Switched to your 6002RS after Taiwanese seals wore out in three months. Yours held up through a full production run." Simple fix, but it saved them downtime costs.

Let's break it down further. The 6002RS isn't some generic import. It's a 6002 series deep groove, ZZ alternatives but with RS nitrile rubber lips that keep out dust better in washdown environments. Grease? Lithium-based, NLGI 2, good to 120°C continuous.

Buyers compare us to SKF 6002-2RS1 or NSK 6002DDU. Fair enough. Ours match ABEC-3 precision (P6 equivalent), but at 40-60% lower cost for wholesale lots. No compromises on chrome steel (GCr15), heat-treated to 58-62 HRC.

Ever dealt with radial play issues? Ours spec at 8-28 microns max, ensuring quiet operation in stepper motors or RC models—yeah, we supply those too.

Market's shifting. With supply chains tightening post-2022, U.S. ops managers are eyeing China direct more. But risks linger: fake certs, poor tolerances. We counter with ISO 9001 audits, RoHS compliance, and full traceability from billet to pack.

This intro alone scratches the surface. Scroll down for specs, apps, and why factories like ours beat distributors. If you're quoting 1K+ units, hit us up—samples ship free for qualified buyers.

Operations tip: Always pair 6002RS with proper shaft fits (h6/g6). Undersized shafts bind; oversized? Premature wear. We've QA'd returns to spot these mismatches early.

In cross-border trade, MOQs matter. We start at 100pcs for 6002RS, scale to pallets. Container loads? 20-foot fits 150K units, mixed with ball screws or linear guides.

Enough upfront. Time to dive into the details that make procurement decisions easier.

6002RS Bearing Technical Specifications

No fluff here. Exact data from our production logs. All units metric, tolerances per ISO 492.

Parameter	Value
Bearing Type	Deep Groove Ball, Double Rubber Sealed (2RS)
Dimensions	ID 15mm x OD 32mm x Width 9mm
Dynamic Load (Cr)	5.60 kN
Static Load (Cor)	2.83 kN
Limiting Speed (Grease)	19,000 RPM
Material	GCr15 Chrome Steel
Seal Type	NBR Rubber (Contact)
Precision Class	P0 (ABEC-1), P6 Optional
Weight	0.030 kg
Grease Type	Lithium NLGI 2

6007rs bearing 6003rs bearing 6002 bearing

Need CAD files or load curves? We email them with your inquiry. Custom seals for high-temp? Runs 10-20% premium.

Where 6002RS Bearings Excel in U.S. Operations

These aren't lab curiosities. U.S. buyers slot them into HVAC fans, electric skateboards, 3D printers, and packaging lines. Radial loads up to 560kg handle conveyor idlers fine.

Motors & Pumps: Quiet, sealed for wet environments. Cuts relube needs by half vs. open 6002.
Automotive Aftermarket: Wheel hubs, alternators. Vibration-tested to 10G.
Food Processing: Washdown-rated with FDA-adjacent seals (inquire for cert).
RC & Robotics: High RPM in small frames. Hobby shops reorder monthly.
Linear Motion Pairing: With our SFU ball screws for CNC upgrades.

Contractor note: In dusty shops, RS seals trap grit better than ZZ metal shields. But check for overheat—above 150°C, swap to open or graphited versions.

One Texas fabricator uses 500/month in plasma table spindles. "No more seizing after 6 months," per their ops lead.

Key Advantages of YIDI 6002RS Over Competitors

Distributors mark up 200%. We cut that. But it's more than price.

Seal Longevity: Contact rubber outlasts non-contact by 2x in contaminated air. Real test: 500 hours misted with shop dust.

Cost Efficiency: $0.80-1.20/unit at 10K MOQ. Vs. $2.50 SKF retail. Same P6 runout.

Procurement pitfall: Cheap no-names vibrate loose. Ours balance to ISO 1940 G2.5.

Feature	YIDI 6002RS	Generic Import
Seal Retention	Excellent	Fair
Noise Level	Low	High
Lead Time	7-15 days	30+ days

ROI? Shops report 15-20% less maintenance calls. Practical, not pie-in-sky.

Smart Procurement Guide for 6002RS Bearings

Risk-averse buyers ask: How to vet suppliers? Start with factory video tours— we offer them live.

6007Rs Bearing

Steps we've refined over 4 years:

Verify ISO 9001 via third-party (SGS links on site).
Request bore runout reports (under 10um target).
Test samples in your rig—free for 50+ unit trials.
Lock pricing with 6-month contracts. Hedged against steel swings.
Plan logistics: Air for urgent (DHL 3 days), sea for bulk.

Warning: Avoid "zero MOQ" scams. They ship rejects. We enforce 100pcs min to ensure QC focus.

OEM/ODM? Stamp your logo, tweak grease, match tolerances. 20% of orders are custom.

Get Custom 6002RS Quote

YIDI Motion Factory Capabilities

Shijiazhuang base, 2020 start. 100 staff, advanced DMG Mori grinders from Germany, Okuma lathes from Japan. Bearing line: 50K/day capacity.

Certifications: ISO 9001:2015, RoHS, REACH. No fake badges—auditable reports.

Vertical Integration: Steel in-house heat treat, no outsourcing variances.
QA Rigor: 100% AQL II inspected, salt spray for seals.
Export Reach: 50 countries, U.S. top 3. Partners like GE suppliers indirectly.

Our edge: One-stop with linear guides, ball splines. Bundle for freight savings.

Logistics from China to USA

Tianjin port, 1 hour drive. Sea: 25-35 days to LA/Long Beach. 20GP: 150K units.

Air: UPS/FedEx, $5-8/kg. Duty? 2.5% on HS 8482.10.

Incoterms: FOB standard, CIF optional. Track via our portal.

Pro tip: Consolidate with other motion parts. Cuts per-unit freight 30%.

What U.S. Buyers Say

Mark T., Ohio Machine Shop: "6002RS arrived perfect. Ran 10K hours no issues. Better than NTN at half price. Reordering 5K."

Sarah L., Texas Distributor: "Samples free, fast ship. Seals held in oily environment. Good for our pump rebuilds."

John R., California Robotics: "Quiet operation in servos. Tolerances spot-on. OEM label next."

Carlos M., Florida HVAC: "Bulk order smooth. No customs hassle. Will bundle with guides."

Frequently Asked Questions on 6002RS Bearings

What's the difference between 6002RS and 6002ZZ?

RS has rubber contact seals—better dirt exclusion, slight friction drag. ZZ metal shields: faster speed, less protection. Pick RS for contaminated spots.
