Vacuum Compatible Linear Stage: Sub-Micron Precision for UHV Chambers – Free Sample Available
Solve your high-cost, low-reliability vacuum motion challenges with OEM-customized stages from YIDI Motion – trusted by US labs and manufacturers.
Get Free Quote in 24hContents
Your Vacuum Motion Challenges: Why Standard Stages Fail
As a purchasing manager or technical director in the US semiconductor, aerospace, or research sectors, you face relentless pressure to deliver ROI-driven precision in ultra-high vacuum (UHV) environments.
- High Prices Eating Budgets: Imported stages cost 2-3x more than needed, with markups from European suppliers hitting 40% on basic models.
- Low Quality & Outgassing: Non-vacuum-compatible materials release gases, contaminating chambers and causing downtime up to 37% per cycle (per SEMI standards).
- Skyrocketing Shipping Costs: Delays from Asia-Europe-US routes add $5K+ per unit, plus tariffs inflating total by 25%.
- Unreliable Customization: Off-the-shelf stages lack OEM/ODM flexibility for your unique chamber sizes, leading to integration failures.
- Poor After-Sales: No local support means weeks for repairs, disrupting production lines.
- Supply Chain Volatility: Competitors' lead times stretch to 12+ weeks amid global disruptions.
These issues compound, slashing your operational efficiency by 30-50%. Ready to cut costs without compromising precision? Explore our solution below.
YIDI Motion's Vacuum Compatible Linear Stage: Engineered for UHV Excellence
HEBEI YIDI IMPORT AND EXPORT TRADING CO., LTD. (YIDI Motion), established in 2020, delivers vacuum compatible linear stages that outperform competitors on price, service, quality, and China's efficient supply chain.
Our powerful factory with 100+ employees (30% senior technicians) uses German/Japanese equipment for unmatched stability. Exported to 50+ countries including the US, we offer OEM/ODM design and high-speed delivery – stages shipped in 2-4 weeks.
Our Shijiazhuang facility: Precision machining in cleanroom conditions.
Core Advantages (5 Key Wins for Your Operations)
- Zero Outgassing Materials: 304/316L stainless steel, ceramic coatings – 10^-9 Torr compatibility, no lubricants needed.
- Sub-Micron Accuracy: <1μm repeatability, ideal for wafer handling and optics alignment.
- Compact & Bellows-Sealed: Magnetic or bellows drive options minimize chamber penetration.
- Cost Savings: 30-50% lower than US/EU brands, with free customization.
- Fast Global Delivery: DHL/FedEx to USA in 7-10 days post-production.
Technical Specifications Table (Optimized for Vacuum Chambers)
Our vacuum compatible linear stages are designed for UHV down to 10^-10 mbar. Below is a comprehensive spec table for our flagship VCL-100 series – one-third of this section dedicated to detailed parameters for SEO and buyer reference.
| Parameter | Specification | Performance Notes |
|---|---|---|
| Travel Range | 50mm to 500mm (custom up to 1m) | Bellows-sealed for full vacuum integrity |
| Positioning Accuracy | ±1μm (bidirectional) | Laser-interferometer calibrated |
| Repeatability | <0.5μm | Cross-roller bearings, no backlash |
| Max Speed | 200mm/s (vacuum-rated stepper/motor) | Magnetic coupling drive option |
| Load Capacity | 10-50kg (horizontal/vertical) | Dynamic/static ratings per ISO standards |
| Vacuum Rating | UHV 10^-9 to 10^-10 Torr | Bakeable to 200°C, low outgassing |
| Materials | SS304/316L, Aluminum 6061-T6 anodized, FKM bellows | RoHS compliant, no organics |
| Drive Options | Manual, stepper, piezo, magnetic linear | Compatible with LabVIEW/EPICS |
| Dimensions (WxHxL) | 50x30x150mm (base model) | Customizable footprints |
| Weight | 1.5-5kg | Lightweight for easy integration |
| MTBF | >10,000 hours | Tested in simulated UHV |
vacuum compatible linear actuator manual linear stage linear stage
These specs ensure high precision vacuum linear stage performance in demanding apps. Detailed performance: Straightness/flatness <2μm/100mm, yaw/pitch/roll <30 arc-sec. Backlash-free design via preloaded bearings supports continuous operation in vacuum chambers.
Application Scenarios & Case Studies
- Semiconductor Fab: Wafer positioning – reduced alignment errors by 45% for a California client.
- Aerospace Testing: Optical alignment in vacuum sims – 99.9% uptime.
- Research Labs: Synchrotron beamlines – custom 300mm travel for NIST-partnered project.
- Photonics: Vacuum chamber linear stage for laser optics, achieving 0.3μm resolution.
Performance characteristics shine in UHV: Low particle generation (<10 particles/cm²), thermal stability ±1μm over 10-40°C. Download brochure for full test data.
