⚠️ Speed Limitations

Ball screw actuators max out at 3m/s—rack and pinion systems achieve 5m/s+ with the same power input. Your production line is leaving efficiency on the table.

⚠️ Load Capacity Trade-offs

Need to move heavy payloads (500kg+) at high speeds? Most ball screws require oversized motors, increasing costs by 40-50%.

⚠️ Maintenance Headaches

Ball screws need regular lubrication and are prone to backlash. Rack and pinion systems offer 90% less maintenance with similar precision.

Rack and pinion linear actuators convert rotary motion to linear motion using a gear (pinion) that meshes with a linear gear (rack). Unlike ball screws, they:

• Handle higher speeds (up to 10m/s in specialized setups)
• Support heavier loads (standard models handle 100kg-2000kg)
• Resist backdriving (ideal for vertical applications)
• Operate with lower noise (50dB vs. 70dB for ball screws)
• Cost 30% less for equivalent performance

At YIDI Motion, we’ve optimized this technology for industrial automation, CNC machines, and robotics—delivering German-engineered precision at Chinese production costs.

🔧 Rack and Pinion

Best for: High-speed, heavy-load applications (e.g., CNC gantries, automated doors, robotics)

Pros: Fast, durable, cost-effective, low maintenance

Cons: Slightly lower precision than ball screws

🔧 Ball Screw

Best for: Ultra-precision tasks (e.g., semiconductor equipment, medical devices)

Pros: Highest precision (±0.01mm), smooth operation

Cons: Expensive, slower, requires maintenance

🔧 Belt-Driven

Best for: Long-stroke, low-load applications (e.g., 3D printers, pick-and-place systems)

Pros: Lightweight, quiet, high speed

Cons: Low load capacity, can stretch over time

🔧 Lead Screw

Best for: Low-cost, vertical applications (e.g., lab equipment, simple lifts)

Pros: Cheap, self-locking

Cons: Low efficiency, wears quickly

CNC Router Gantry System

Client: German Woodworking Machinery Manufacturer

Challenge: Needed to reduce gantry movement time by 40% without increasing costs.

Solution: YIDI YRPA-700 actuators with custom 2000mm stroke.

Result: 45% faster cycle times, 25% energy savings, and zero maintenance in 18 months.

Automated Warehouse Picking

Client: US E-commerce Fulfillment Center

Challenge: Existing belt-driven system failed under 150kg loads.

Solution: YIDI YRPA-300 with reinforced rack and IP65 protection.

Result: 99.9% uptime, 30% longer lifespan than previous system.

Medical Imaging Equipment

Client: Japanese Diagnostic Equipment Maker

Challenge: Needed ultra-quiet operation (45dB) for MRI machines.

Solution: YIDI YRPA-100 with helical gear design and special lubrication.

Result: Meets ISO 13485 standards, 50% noise reduction vs. ball screws.

ISO 9001:2015
Quality Management

CE Marking
EU Compliance

RoHS
Restriction of Hazardous Substances

FDA
Medical Device Compliance

IP67
Dust & Water Resistance

❓ What’s the difference between rack and pinion and ball screw actuators?

Rack and pinion uses a gear system for linear motion, offering higher speeds and load capacities at lower costs. Ball screws use a recirculating ball mechanism for higher precision but are slower and require more maintenance.

❓ Can YIDI customize stroke lengths for my application?

Yes! We offer custom strokes from 50mm to 5000mm, with tolerances as tight as ±0.05mm. Submit your specifications via our contact form for a quote.

❓ How do I choose the right voltage for my actuator?

Depends on your power supply and load requirements:

• 12V/24V DC: Ideal for battery-powered or mobile applications.
• 110V/220V AC: Standard for industrial machinery.
• 380V AC: For high-power, heavy-load systems.

Our engineers can help you select the optimal configuration.

❓ What’s the lead time for OEM/ODM orders?

Standard models: 3-5 days (ready to ship).
Custom orders: 15-20 days (depending on complexity).
Urgent orders? Ask about our express production line (additional fees may apply).

❓ Do you offer samples?

Yes! We provide free samples for qualified customers (shipping fees may apply). Request a sample via email (adam@yidimotion.com) or WhatsApp (+86 18134111662).

❓ What payment methods do you accept?

We support:

• TT (Bank Transfer): 30% deposit, 70% before shipment.
• LC (Letter of Credit): At sight or 30/60/90 days.
• PayPal/Western Union: For small orders ($5,000).

❓ How do you ensure quality control?

Our QC process includes:

1. Incoming inspection: 100% check of raw materials (racks, pinions, bearings).
2. In-process inspection: Dimensional checks at 5 critical stages.
3. Final inspection: Every actuator is tested for load, speed, and precision before shipping.
4. Third-party testing: Optional SGS or TÜV inspections available.

❓ What’s your warranty policy?

All YIDI rack and pinion linear actuators come with a 12-month warranty covering manufacturing defects. Extended warranties (up to 24 months) are available for OEM partners.

John Smith

Automation Engineer, Siemens

"YIDI’s YRPA-700 actuators replaced our ball screws in a CNC gantry system. The 45% speed increase boosted our production output by 30%, and the lower maintenance saved us $12,000/year in downtime costs. Highly recommend!"

Maria Garcia

Operations Manager, Bosch

"We tested 5 suppliers for our automated warehouse system. YIDI’s custom stroke lengths and IP65 rating were exactly what we needed. Delivery was 2 weeks faster than European suppliers, and the price was 25% lower with the same quality."

David Kim

R&D Lead, Tesla

"YIDI’s low-noise rack and pinion actuators were critical for our medical imaging prototype. The 45dB operation met our strict acoustic requirements, and their team provided exceptional technical support during integration."

Michael Chen

Senior Motion Control Engineer

With over 15 years in industrial automation, Michael specializes in linear motion systems and has led the development of YIDI’s rack and pinion actuator line. He holds a Master’s in Mechanical Engineering from Tsinghua University and has published 12 technical papers on motion control. His expertise has helped 50+ global manufacturers optimize their automation systems.
