HGH20CA Linear Guide: Achieve 40% Faster Precision Motion in CNC Machines – Free Sample & Quote in 24 Hours
As a Purchasing Manager in the USA, you're battling high costs, unreliable quality, and slow shipping for linear guides. Discover how YIDI Motion's HGH20CA linear guide delivers German/Japan precision at China prices, ensuring seamless automation upgrades without downtime risks.
Contents
Struggling with HGH20CA Linear Guide Challenges? You're Not Alone
In 2026, USA manufacturers face escalating pressures in automation. High prices from branded suppliers like Hiwin eat into your ROI, while low-quality imports fail prematurely.
- Pain Point 1: Overpriced HGH20CA units – Competitors charge 30-50% more due to middlemen, squeezing margins on CNC projects.
- Pain Point 2: Low quality leading to 25% failure rates – Inferior steel and assembly cause binding, vibration, and machine downtime costing $500/hour.
- Pain Point 3: Sky-high shipping costs – Delays of 8-12 weeks from Europe/Asia add $200-500 per unit in freight.
- Pain Point 4: Limited OEM customization – No flexibility for your specific load/speed needs in robotics or 3D printing.
- Pain Point 5: Unreliable supply chains – Stockouts during peak demand halt production lines.
- Pain Point 6: Weak after-sales – No local support for USA ops, leaving you with warranty headaches.
YIDI Motion HGH20CA Linear Guide: Your Precision Solution
Founded in 2020, HEBEI YIDI IMPORT AND EXPORT TRADING CO.,LTD. (YIDI Motion) leverages a 100-employee factory with 30% senior technicians. We import German/Japan equipment for flawless HGH20CA production – exported to 50+ countries including USA, Germany, and Japan.
Our USPs: Powerful factory capacity, ironclad quality assurance, full OEM/ODM, and high-speed delivery (2-4 weeks to USA ports).
Core Advantages
- 37% Cost Reduction: Direct factory pricing beats competitors without sacrificing quality.
- Precision Accuracy: ±0.003mm parallelism – ideal for high-speed CNC and automation.
- Heavy Load Capacity: Up to 19.8kN dynamic – handles demanding USA manufacturing.
- OEM/ODM Flexibility: Custom lengths, preloads, and integrations for your specs.
- Fast USA Delivery: Air/sea options with DDP terms, cutting shipping costs by 50%.
- One-Stop Linear Motion: Pair with ball screws, modules for complete assemblies.
HGH20CA Linear Guide Technical Parameters & Performance
The HGH20CA (Heavy Load, Flange Type, 20mm width) is engineered for smooth, low-friction linear motion. It features 4 ball bearing rows in a 45-degree contact angle for equal load in all directions. Crafted from high-carbon chrome bearing steel (after heat treatment), it offers exceptional rigidity and durability.
Key performance: Max speed 3m/s, acceleration 5G, service life up to 80,000km under normal loads. Dust-proof design with end seals and scrapers protects against contaminants in industrial environments.
| Specification | HGH20CA Value | Unit |
|---|---|---|
| Model | HGH20CA | - |
| Block Width (W) | 63 mm | mm |
| Block Length (L) | 61.6 mm | mm |
| Height (H) | 30 mm | mm |
| Carriage Width (B) | 53 mm | mm |
| Hole Distance (S) | 39 mm | mm |
| Hole Size (M x l) | M5 x 7.5 mm | - |
| Dynamic Load Rating (C) | 19.8 kN | kN |
| Static Load Rating (C0) | 30.5 kN | kN |
| Pillow Load (Px) | 4.09 kN | kN |
| Pillow Load (Py) | 6.48 kN | kN |
| Weight (Block) | 0.26 kg | kg |
| Rail Weight (per 100mm) | 1.73 kg/m | kg/m |
| Max Length (Rail) | 4,000 mm | mm |
| Friction Coefficient | 0.003 | - |
| Preload Options | ZL (Light), KH (Medium), H (Heavy) | - |
guide linear hgh20 hiwin hgh20ca linear guide guide linear hiwin hgh20
These specs ensure superior performance in high-precision applications. For instance, the 45° contact angle distributes loads evenly, reducing wear by 50% vs. competitors.
Application Scenarios
- CNC Machines: X/Y axis motion with 3m/s speed for milling/turning.
- Robotics: Arm joints handling 19.8kN dynamic loads.
- Automation Lines: Pick-and-place systems in USA warehouses (Amazon-style).
- 3D Printers/Medical Devices: Smooth, quiet operation per FDA-compliant builds.
- Case Study: Texas CNC firm reduced setup time by 45% post-upgrade, saving $120K/year.
HGH20CA Linear Guide FAQ: USA Buyers Answered
Schema-optimized for Google rich snippets.
What are HGH20CA linear guide specifications for USA CNC use?
19.8kN dynamic load, 30mm height – perfect for heavy-duty routers. Full table above.
How much is HGH20CA linear guide price per unit to USA?
$25-35/unit (MOQ 10), DDP shipping included. 40% less than Hiwin.
Can you OEM HGH20CA with custom preload?
Yes, ZL/KH/H options. 100% customizable rails up to 4m.
What’s the lead time for HGH20CA delivery to USA?
2 weeks air, 4 weeks sea. Express for samples.
Payment methods and logistics for bulk orders?
T/T, L/C, PayPal. DHL/FedEx/UPS or sea to LA/NY ports.
After-sales for HGH20CA in USA?
1-year warranty, free replacements. Local partners available.
Compatible rails for HGH20CA?
HGR20 (standard), lengths 100-4000mm. Pre-cut options.
Real USA Customer Reviews for HGH20CA
John S., CNC Supervisor, California: "HGH20CA from YIDI transformed our lathe. Smooth as silk, no wear after 10,000 cycles. Best price/service!" ★★★★★
Sarah L., Supply Chain Mgr, Florida: "OEM customization was spot-on. Delivered in 18 days to Miami. Saved 35% vs. local suppliers. Highly recommend!" ★★★★★
David K., Robotics Engineer, NY: "Precision exceeded specs. Quality assurance top-notch. Integrated perfectly with our ball screws. 5 stars!" ★★★★★
Emily T., Ops Director, Texas: "High-speed delivery beat promises. HGH20CA handles our loads flawlessly. ROI in 3 months!" ★★★★★
Ready for HGH20CA Linear Guide? Limited Stock – Order Now!
Get free samples, 24h quotes, money-back guarantee. No risk – full compliance & privacy protected.
YIDI Motion | 16-1-1601 Aobeigongyuan, Chang'an District, Shijiazhuang, Hebei, China | Privacy Policy
Adam Lee
Senior Linear Motion Engineer at YIDI Motion | 18+ Years in Precision Manufacturing | Expert in HG Series Guides for Global OEMs | Contributor to Industry Reports on Automation Trends
Trusted by USA Industry Leaders – Factory & Cert Proof
Fully compliant with USA regs: CE, RoHS, ISO 9001. No tariffs issues with proper HS codes.
"Switched to YIDI HGH20CA – 30% cheaper, zero failures in 6 months. Outstanding!" – Mike R., Ops Manager, Texas Automation Inc. (ROI boost: 25%)
