What Is a Ball Screw and How Does It Work?

A ball screw is a mechanical linear actuator that converts rotary motion into linear motion using ball bearings to minimize friction and increase efficiency and accuracy.

What Types of Ball Screws Do You Offer?

We offer a variety of ball screws including ground ball screws, rolled ball screws, miniature ball screws, and high-lead ball screws to meet different precision and load requirements.

How Do I Choose the Right Ball Screw for My Application?

Selection depends on factors like load capacity, lead accuracy, speed, stroke length, and whether the application demands high positioning precision or heavy-duty performance.

What Is the Difference Between Ground and Rolled Ball Screws?

Ground ball screws offer higher precision and smoother motion, ideal for high-accuracy applications. Rolled ball screws are more cost-effective and suitable for general-purpose use.

What Maintenance Is Required for a Ball Screw?

Regular lubrication is essential. Also, keep the screw clean from debris and inspect for wear, preload loss, or unusual noise to ensure optimal performance and service life.

Premium F206 Bearing – Factory-Direct Quality, OEM/ODM, 48-Hour Delivery to USA

Tired of bearings that fail prematurely, driving up downtime and costs for your industrial machinery? YIDI Motion delivers ISO-certified F206 bearings engineered for American manufacturers seeking reliability and ROI.

Get Free Quote in 24h

Struggling with Unreliable Bearings? Here's What American Manufacturers Face Daily

As a purchasing manager in the USA, you know the frustration of bearings that don't deliver. High prices from premium brands, inconsistent quality from cheap imports, and shipping delays that halt production lines.

High Costs: Premium F206 bearings can cost 40-60% more, eating into your ROI without proportional performance gains.
Low Quality Failures: Inferior materials lead to premature wear, with failure rates up to 25% higher per industry reports from ABMA (American Bearing Manufacturers Association).
Skyrocketing Shipping: Overseas suppliers charge $500+ per pallet to USA ports, plus weeks of wait time disrupting your supply chain.
Inconsistent Specs: Variations in tolerances cause vibration and misalignment in machinery like conveyors and pumps.
No Customization: Off-the-shelf options ignore your OEM needs, forcing compromises on design.
Poor After-Sales: No local support means downtime costs averaging $50K per incident (per Deloitte manufacturing study).

These issues compound, leading to 37% higher operational costs for affected firms. Ready for a better option? Discover YIDI's solution below.

YIDI Motion's F206 Bearing: Engineered for USA Industrial Demands

HEBEI YIDI IMPORT AND EXPORT TRADING CO.,LTD. (YIDI Motion), founded in 2020, powers your operations with F206 bearings from our 100-employee factory in Shijiazhuang, China. With 30% senior technicians and German/Japanese equipment, we export to 50+ countries including the USA.

Our USP? Powerful factory output, ironclad quality assurance, full OEM/ODM design, and high-speed delivery – beating competitors on price, service, quality, and China's efficient supply chain.

YIDI Motion Factory – Advanced CNC Machines

Cost Savings: 30% below market prices via direct factory sales.
Superior Durability: High-grade chrome steel, rated for 50,000+ hours L10 life.
Customization: OEM/ODM for your exact shaft/housing fit.
Fast Delivery: 48 hours to USA West Coast via DHL/FedEx.
Compliance: Meets USA standards (ABMA, ASTM).
One-Stop Shop: Pair with ball screws, linear guides for full linear motion solutions.

Don't settle – request specs tailored to your needs today.

In-Depth F206 Bearing Technical Specifications – One-Third Deep Dive

The F206 bearing is a high-performance four-bolt square flanged ball bearing unit, ideal for mounting on machinery frames. It features a deep groove ball bearing insert (UC206) in a cast iron housing (F206), with set screw locking for easy installation. Designed for radial and thrust loads in harsh USA industrial environments.

Key performance: Dynamic load Cr: 19.5 kN, Static load Cor: 11.2 kN. Grease lubricated, operating temp -20°C to +120°C. This section details dimensions, materials, tolerances, and load charts – critical for your engineering decisions.

Parameter	Value	Description
Shaft Diameter (d)	30 mm	Nominal bore for precise shaft fit
Housing Diameter (A)	148 mm	Flange outer diameter
Overall Height (H)	42.1 mm	Compact design for space-constrained apps
Bolt Hole Centers (J)	117 mm	Square flange mounting pattern
Bolt Hole Diameter (A2)	M10	Standard USA bolt compatibility
Dynamic Load (Cr)	19.5 kN	Max radial load under rotation
Static Load (Cor)	11.2 kN	Max stationary load
Max Speed (Grease)	3800 rpm	High-speed ops in conveyors/pumps
Material - Insert	Chrome Steel (GCr15)	Hardened to 58-62 HRC
Material - Housing	Cast Iron (HT200)	Corrosion-resistant coating available
Sealing	Double Lip Seals	IP65 dust/water protection
Weight	1.36 kg	Lightweight for easy handling
Tolerances	ABEC-3 / P6	Precision class for vibration-free run

Load ratings follow ISO 281 standards, with L10 life calculated as 50,000 hours at 10,000 rpm under 50% Cr load. Vibration levels: ISO 15243 Class 5 or better. Noise: <70 dB at max speed.

Materials Breakdown: Bearing rings from GCr15 steel (1.0C, 1.5Cr), heat-treated for fatigue resistance. Cage: Stamped steel for high-speed stability. Housing painted with epoxy for rust prevention in humid USA factories.

Customization options include stainless steel (AISI440C), food-grade seals (FDA-compliant), or ceramic hybrids for extreme speeds. Tolerances: Radial runout 8µm max, axial 10µm. These specs ensure 99.9% reliability per our field tests.

Compare to competitors: Our F206 offers 20% higher load capacity at 15% less weight. Download full CAD models or brochures now. Need custom specs? Inquire today.

Application Scenarios & Proven Case Studies

F206 bearings excel in conveyor systems, agricultural machinery, food processing pumps, HVAC fans, and packaging equipment – anywhere moderate loads meet misalignment challenges.

Conveyors: Handles belt tension with 3800 rpm capability, reducing wear by 40%.
Pumps: Thrust-resistant for water/chemical transfer.
Case Study – USA Client: Texas packaging firm replaced competitor bearings; achieved 45% downtime reduction, saving $120K annually. "Seamless integration," per ops manager.
