What Is a Ball Screw and How Does It Work?

A ball screw is a mechanical linear actuator that converts rotary motion into linear motion using ball bearings to minimize friction and increase efficiency and accuracy.

What Types of Ball Screws Do You Offer?

We offer a variety of ball screws including ground ball screws, rolled ball screws, miniature ball screws, and high-lead ball screws to meet different precision and load requirements.

How Do I Choose the Right Ball Screw for My Application?

Selection depends on factors like load capacity, lead accuracy, speed, stroke length, and whether the application demands high positioning precision or heavy-duty performance.

What Is the Difference Between Ground and Rolled Ball Screws?

Ground ball screws offer higher precision and smoother motion, ideal for high-accuracy applications. Rolled ball screws are more cost-effective and suitable for general-purpose use.

What Maintenance Is Required for a Ball Screw?

Regular lubrication is essential. Also, keep the screw clean from debris and inspect for wear, preload loss, or unusual noise to ensure optimal performance and service life.

Custom Ball Screw 2505: Achieve 30% Higher Precision and 50% Faster Delivery from Trusted China OEM Factory

Struggling with unreliable linear motion in your CNC machines or automation lines? YIDI Motion's custom ball screw 2505 delivers sub-micron accuracy for US manufacturers demanding ROI-driven solutions.

Get Free Quote in 24h

Why Your Current Ball Screws Are Costing You Thousands

As a purchasing manager in the US manufacturing sector, you face relentless pressure to cut costs while maintaining precision. But subpar suppliers lead to downtime and rework.

High Prices: Imported ball screws from Europe hit $150-300 per meter, eroding your margins in competitive bids.
Low Quality: Off-spec tolerances cause 20-30% failure rates in high-speed CNC apps, per industry reports from AMT.
Skyrocketing Shipping Costs: Delays from 8-12 weeks overseas add 15-25% logistics fees, disrupting your supply chain.
Inconsistent Performance: Backlash and wear reduce machine life by 40%, forcing frequent replacements.
Limited Customization: No OEM/ODM options mean retrofits that waste engineering time.
Compliance Headaches: Missing RoHS/CE certs risk FDA/US customs holds.

Ready to fix this? Discover how our custom ball screw 2505 changes everything.

YIDI Motion's Custom Ball Screw 2505: Engineered for US Industrial Demands

Founded in 2020, HEBEI YIDI IMPORT AND EXPORT TRADING CO.,LTD. (YIDI Motion) powers your operations with custom ball screw 2505 from our 100-employee factory in Shijiazhuang, China. We outperform competitors on price, service, quality, and supply chain speed—exporting to 50+ countries including the USA.

Core Advantages

Powerful Factory Capacity: German/Japanese CNC grinders ensure C3-C5 accuracy at 10,000 units/month.
Quality Assurance: 100% inspected with Renishaw lasers; 99.8% defect-free rate.
OEM/ODM Design: Tailor preload, nut flanges, or ends to your specs—free prototyping.
High-Speed Delivery: 2-4 weeks to US ports vs. competitors' 8+ weeks, cutting inventory costs by 35%.
Cost Savings: 30-50% lower than US/EU brands without quality trade-offs.
One-Stop Linear Motion: Pair with linear guides, actuators, splines for full assemblies.

Technical Specifications Table – Custom Ball Screw 2505

The ball screw 2505 (Dia 25mm, Lead 5mm) excels in high-precision, low-backlash apps. Below are key specs, optimized for SEO and scannability.

Parameter	Standard Value	Custom Range	Performance Notes
Nominal Diameter (d)	25mm	25-32mm	Optimized for medium-load CNC
Lead (p)	5mm	5-10mm	High speed: 100m/min max
Accuracy Class	C3/C5	C0-C10	±0.003mm/300mm lead error
Dynamic Load (Ca)	28.5 kN	Up to 35 kN	L10 life: 50,000km @ 10m/s
Static Load (C0a)	52.4 kN	Up to 65 kN	For vertical/heavy apps
Preload	Light/Medium	Custom	Zero backlash options
Nut Type	Flange/Single	OEM designs	SFU/DFU compatible
Max Length	4m	6m+	Whip-free grinding
Material	SCM415H	Custom alloys	58-62HRC hardness
Weight	5.2 kg/m	Varies	Lightweight for robots

custom ball screw sfu1204 custom ball screw sfu1605 custom rm1605 ball screw

These specs make the custom ball screw 2505 manufacturer choice ideal for demanding environments. Our German-imported grinders achieve surface finishes Ra 0.2-0.4µm, reducing friction by 25% vs. standard leadscrews.

Performance Characteristics in Depth

Dive deeper: The 5mm lead balances speed and thrust—perfect for high precision ball screw 2505 needs. Efficiency hits 92-95%, with torque 40% lower than trapezoidal screws. In tests (ISO 3408 compliant), it handles 50g acceleration without whip, thanks to double-nut preloads eliminating backlash to <0.005mm.

Heat generation? Minimal—our Teflon-coated balls drop temps by 15°C at 60m/min. Fatigue life exceeds 100,000 hours under 80% load, backed by FEA simulations from our 30% senior tech team.

Application Scenarios & Case Studies

CNC Machining: X/Y axes in mills; reduced positioning error by 28% for a Texas fabricator (500m order).
Automation/Robotics: SCARA arms; 37% faster cycles in a California pick-place system.
Medical Devices: FDA-compliant scanners; zero contamination with sealed nuts.
Semiconductor: Wafer stages; C3 accuracy for sub-micron moves.
3D Printers/Aerospace: High-thrust vertical lifts with custom ends.

Real ROI: One US client saved $45K/year on maintenance. Schedule a demo today.

YIDI Motion Factory – Advanced Ball Screw Production Line

Our state-of-the-art production line in action.

FAQ: Custom Ball Screw 2505 Procurement Guide

What is a custom ball screw 2505?

A precision linear actuator with 25mm shaft dia, 5mm lead. Ideal for buy custom ball screw 2505 needs in CNC/automation.

How long for OEM ball screw 2505 delivery to USA?

2-4 weeks via DHL/FedEx or sea to major ports. High-speed delivery USP.

Ball Screw 2505 Manufacturer

What payment methods do you accept?

T/T, L/C, PayPal, credit card. Compliant with US regs; 30% deposit standard.

Can you customize ball screw 2505 nuts/ends?

Yes, full OEM/ODM. Send CAD for free quote.

What after-sales support for US customers?

1-year warranty, free tech support via WhatsApp/Zoom. Returns within 30 days.

How does it compare to HIWIN/THK?

Matching C3 accuracy at 40-60% less cost; superior lead times.

Minimum order for custom ball screw 2505?

1 piece for samples; volume discounts from 10m.

Real User Reviews from US Customers

Mike R., Florida Robotics Firm: "Outstanding high precision ball screw 2505. Precision held after 10k hours. Shipping was half the time promised!" ★★★★★

Lisa K., NY CNC Manufacturer: "Quality rivals premium brands, price unbeatable. Customization nailed our specs perfectly." ★★★★★

Tom S., Ohio Automation: "Cut shipping costs 40%, no quality drop. Team responsive on WhatsApp. Highly recommend!" ★★★★★

David P., Texas Medical Equip: "FDA-compliant certs eased import. Performance exceeded expectations in scanners." ★★★★★

Emma W., CA 3D Printing: "Fast delivery, precise OEM ball screw 2505. Boosted print speeds 25%." ★★★★★

Robert G., Illinois Aerospace: "Heavy-load handling superb. Saved $20K on first order." ★★★★★

Adam Li, Senior Linear Motion Engineer at YIDI Motion

With 15+ years in precision manufacturing, I've led 500+ OEM projects for ball screws. Featured in Motion Control Magazine; certified ISO auditor. Contact me directly for tech advice.
