3720 Bearing: Reliable Thrust Roller Solutions for Demanding Industrial Loads
Sourcing the right 3720 bearing isn't just about specs—it's about matching load capacity to your uptime needs. We've shipped thousands to U.S. fabricators facing axial thrust challenges in cranes and extruders. Request factory-direct pricing today.
Table of Contents
Common Pitfalls When Sourcing 3720 Bearings
Purchasing managers know the drill. You spec a 3720 bearing for axial loads in your gear reducer, but the supplier cuts corners on steel quality. Suddenly, you're dealing with premature spalling under 120kN dynamic thrust.
We've seen it too often—importers from Texas crane outfits ordering from unvetted Alibaba listings, only to face weeks of downtime when cages deform at high RPMs. One client lost a full production shift because the bearing's roller geometry wasn't precision-ground, leading to uneven load distribution.
Risk number one: mismatched tolerances. A 3720 needs ABEC-3P or better to handle misalignment in screw conveyors. Cheaper units drift to P0 equivalents that vibrate loose.
Then there's lead time roulette. Spot market quotes promise 7 days, but ocean freight from secondary factories hits 45-60 days. Your inventory buffer vanishes.
Don't overlook certification gaps. U.S. ops demand RoHS compliance for assembly lines, yet many Asian suppliers skip it. Factor in logistics too—container stuffing errors mean bearings arrive with brinelling from rough handling.
Procurement tip: Always request bore runout data under 8 microns. It separates factory-direct reliability from reseller guesswork.
Understanding the 3720 Bearing Design
The 3720 bearing falls into the thrust roller category, optimized for pure axial loads. Picture a single-direction setup: machined brass cage holding cylindrical rollers between a shaft washer and housing washer. Bore diameter sits at 100mm, OD 150mm, with a 30mm height—compact yet rated for serious duty.
Engineered from GCr15 chrome steel, hardened to 58-62 HRC, it shrugs off fatigue from pulsating thrusts. Rollers are surface-ground for logarithmic profiles, reducing edge stress in misaligned setups. That's key for applications like paper mill calenders where shafts aren't perfectly parallel.
Dynamic load capacity hovers around 150-160kN, static at 280kN, per ISO 76 standards. Speed limits? Oil-lubed, it pushes 3000 RPM; grease drops to 2000. We've tested these in-house on dynamic rigs mimicking extruder peaks.
What sets it apart from ball thrust types? Rollers handle 3-5x the load without skidding. But watch PV factors—pair it wrong with your housing, and heat buildup spikes.
Operational note: Minimum load is 0.05Co to prevent slippage. Undersized thrusts chew cages fast.
Diving deeper, the 3720's washer faces are flat-ground, no self-aligning like spherical rollers. Precision mounting is non-negotiable. Tolerance class P6 standard, but we offer P5 for high-precision wind turbine yaw drives.
Key Advantages of YIDI's 3720 Bearing
- Superior roller retention—brass cage machined from solid barstock, resists centrifuging at max speeds.
- Extended L10 life: 2-3x over generic imports due to refined heat treatment.
- Versatile lubrication ports on both washers for relubrication without disassembly.
- Cost-effective OEM scaling—we've tooled for 10k+ annual volumes without MOQ hikes.
- Risk-mitigated: Full traceability from steel melt to packing slip.
Buyers tell us the real win is interchangeability. Our 3720 slots into SKF 81120 or FAG 3720 footprints without re-machining housings.
Short take: Less unplanned stops. One Midwest pump maker cut thrust failures by half after switching.
Where the 3720 Bearing Excels
In mining crushers, it takes axial forces from helical gears without flinching. Cranes? Hoist gearboxes lean on it for overload protection.
Extrusion lines love the compactness—fits tight envelopes in plastic blow molders. Marine winches too, where saltwater demands chrome steel toughness.
We've supplied to U.S. steel mills for slab caster tables. Radial loads creep in? Pair with a 6220 deep groove for combo duty.
Less obvious: Textile winders. Constant stop-start cycles test fatigue resistance; 3720 delivers.
3720 Bearing Technical Specifications
| Parameter | Value |
|---|---|
| Bore Diameter (d) | 100 mm |
| Outer Diameter (D) | 150 mm |
| Height (T) | 30 mm |
| Dynamic Load (C) | 158 kN |
| Static Load (C0) | 280 kN |
| Reference Speed | 3000 RPM |
| Limiting Speed (Oil) | 4500 RPM |
| Weight | 1.45 kg |
| Material | GCr15 Chrome Steel |
| Cage | Machined Brass |
| Tolerance | P6 / P5 Optional |
32010 bearing 32008 bearing 32240 bearing
Values per ISO 199:2014. Custom variants available for extreme environments.
Practical Installation Notes for 3720 Bearings
Mounting a 3720 starts with clean shafts. Heat the housing washer to 80°C max—beyond that, tempering suffers. Use an arbor press for the shaft washer; hydraulic rams risk roller damage.
Alignment is everything. Shaft deflection over 0.01mm/100mm span kills life. Torque housing bolts to 50Nm sequence.
Lube it right: EP2 grease initial fill 30-50%. Relube intervals? 5000 hours under 70% load. Watch for whip—add axial play 0.5-1mm.
Pro tip: Induction heat rings separately. Torch methods warp faces.
Global Shipping from Hebei YIDI
Lead time: Stock 100-500 pcs ships DHL 3-5 days to USA. Bulk? 20-30 days FOB Tianjin.
20' container holds 8000 pcs palletized in anti-rust paper, VCI bags. Duty? HS 8482.50, often 0% under USMCA paths.
We've cleared Chicago customs weekly—no holds from improper packing. Track via adam@yidimotion.com.
Why YIDI Motion Factory Stands Out
Since 2020, our 100-person team in Shijiazhuang cranks 3720s on DMG Mori grinders from Germany. Senior techs (30%+) oversee grind cycles holding 2-micron geometries.
OEM/ODM? Full suite—from CAD tweaks to private labeling. Exported to 50+ countries: GE wind ops in Texas, Canadian miners.
Certifications: ISO 9001:2015, RoHS, CE marked. Full metrology lab with Zeiss CMMs verifies every batch.
Contact: +86 18134111662 | 16-1-1601 Aobeigongyuan, Chang'an District, Shijiazhuang, Hebei, China.
Quick Procurement Checklist for 3720 Bearings
- Verify dynamic rating vs. your peak thrust.
- Request P5 tolerance cert for precision fits.
- Ask for grease compatibility data.
- Confirm cage material—brass over steel for heat.
- Get sample before bulk—test in your rig.
- Negotiate FOB pricing tiers.
Ready to spec? Email for CAD drawings.
3720 Bearing FAQs
What's the max temp for 3720? Continuous 120°C with standard grease; 150°C synthetic. Avoid 200°C peaks.
Can I get it in stainless? Yes, AISI 440C for corrosive duties—quote separately.
MOQ for OEM? 50 pcs start; scales down for stock.
Interchange with NTN? Direct drop-in for TN20 model.
Lead time to West Coast USA? Air: 7 days; sea: 25 days average.
Feedback from Procurement Pros
Mike R., Operations Mgr, Texas Crane Co.
Switched to YIDI 3720 after SKF delays. Held 140kN no sweat. Lead time beat quotes by 10 days.
Sarah L., Buyer, Ohio Steel Mill
OEM run of 200 pcs arrived perfect. RoHS docs sped customs. Life tripled vs. prior import.
Tom K., Engr, Canada Pump Fab
P5 tolerance spot-on for our misalignment. Pricing 20% under list. Will reorder racks too.
Javier M., Supply Chain, Mexico Extruder
Sample tested fine; bulk shipped flawless. Brass cage key for our heat.
Need 3720 Bearings Now?
Talk to our engineers. Get specs, samples, or a custom quote.
+86 18134111662 | adam@yidimotion.com
About the Author
Li Wei, Export Director at YIDI Motion
15 years in bearing production, overseeing exports to North America. Hands-on with thrust roller grinding and OEM validations. Based in Shijiazhuang factory.
Last updated: October 2026
